Makita 12 Amp 6-1/2 in. Plunge Circular Saw with Guide Rail Connector Kit
Makita 6-1/2 in. Plunge Circular Saw + Guide Rail Connector Kit
Precise plunge-cutting power with a 12-amp motor and variable speed delivers smooth, splinter-free results. Includes the 55 in. guide rail and P-45777 connector kit for extended, dead-straight cuts on wood panels and cabinetry.
Key Features:
- Powerful Motor & Control: 12-amp motor with variable speed dial (2,000–5,200 RPM) maintains constant speed under load
- Large Cutting Capacity: Cuts up to 2-3/16 in. at 90° and 1-9/16 in. at 45° with -1° to 48° bevel and positive stops at 22.5° and 45°
- Precision Track Cutting: 55 in. guide rail plus connector kit joins rails for longer straight or bevel cuts; compatible with select competitor rails
- Clean Work Area: 1-1/2 in. dust port connects to vacuums to direct debris away for better visibility
- User-Friendly Features: Soft start, easy depth adjustment, dual bevel supports, and locking lever for quick blade changes
Please check the Product Data Sheet Here
Specifications Table:
| Specification | Details |
|---|---|
| Amperage | 12 A |
| Maximum Speed | 5200 RPM |
| Variable Speed Range | 2000–5200 RPM |
| Blade Diameter | 6-1/2 in |
| Bevel Capacity | -1° to 48°; positive stops at 22.5° and 45° |
| Maximum Cut Depth at 90° | 2-3/16 in (2.188 in) |
| Maximum Cut Depth at 45° | 1-9/16 in (1.563 in) |
| Blade Location | Right |
| Cord Length | 7.9 ft |
| Corded/Cordless | Corded |
| Tool Type | Circular Saw |
| Cuts Through | Wood |
| Included Accessories | 6-1/2 in 48T carbide blade, hex wrench, 55 in guide rail, guide rail connector kit (P-45777), stackable tool case |
| Power Tool Features | Depth adjustment, keyed blade change, spindle lock, soft start, built-in current limiter |
| Dust Port | 1-1/2 in O.D. |
| Close-to-Wall Cutting | 11/16 in |
| Bevel Support | Dual front and rear supports |
| Product Dimensions (W x H x D) | 11.7 in x 12.4 in x 15.5 in |
| Color Family | Teal |
| Construction Material | Magnesium components; plastic housing |
| Saw Drive Type | Sidewinder |
| Certifications and Listings | UL Listed |
| Manufacturer Warranty | 1 Year |
| Compatibility (Connector Kit) | For Makita 118 in (194367-7), 55 in (194368-5), 39 in (199140-0) rails; compatible with Festool, Bosch, DEWALT rails |
Frequently Asked Questions (FAQ):
Q: What’s included in the kit?
A: Circular saw, 6-1/2 in. 48T carbide blade, hex wrench, 55 in. guide rail, guide rail connector kit (P-45777), and stackable tool case.
Q: Can the saw connect to a vacuum?
A: Yes, it has a 1-1/2 in. dust port that connects to most vacuum systems.
Q: What materials can it cut?
A: Designed primarily for wood and wood-based panels; use appropriate blades for specific materials.
Q: What are the bevel capabilities?
A: Bevel from -1° to 48° with positive stops at 22.5° and 45° for repeatable cuts.
Q: Is there a warranty?
A: Yes, it carries a 1-year manufacturer warranty.
Architectural lines, flawless cuts
This plunge saw glides with couture precision, turning raw panels into tailored planes. The magnesium build and track system deliver crisp, splinter-free edges that feel bespoke. Pair it with extended rails to choreograph long, uninterrupted cuts across cabinetry or wall paneling. It’s the essential instrument for elevated, modern craft.
Elevate your finish—add this Makita plunge saw kit to your cart for precision, clean cuts, and pro-level control.
